主要技术参数
涂胶电机功率Gluing motor power |
0.75KW |
预铣电机Pre-milling motor power |
2.2*2=4.4KW |
齐头电机功率End trimming motor power |
0.37*2=0.74KW |
精修电机功率Fine trimming motor power |
0.75*2=1.5KW |
抛光电机功率Buffing motor power |
0.37*2=0.74KW |
跟踪电机Corner trimming motor power |
0.3*2=0.6KW |
主电机Main motor power |
2.2kw |
板材最小加工宽度Min width of the wood |
≥80mm |
板材最小加工长度Min length of the wood |
≥160mm |
进料速度Feeding speed |
12-20m/min |
工作气压Air pressure |
0.6Mpa |
电压Voltage |
380V/50HZ 3Phase |
机器重量Total weight |
2000KG |
外形尺寸Overall size |
5200mm*1100mm*1600mm |
