Technical parameters:
Pushing table size: 1600 * 375mm flat laser cutting, cutting and unloading body, 10mm thick steel plate frame, body linear guide rail lifting, electric lifting, angle manual tilting. For solid wood small equipment.
Cutting length: 1600mm
Maximum cutting width: 1200mm (customizable size)
Main saw blade diameter: 400mm (customizable from 500-550mm)
Saw blade tilt 90 ° -45 °
Saw blade lifting height: 120-130mm
Main saw speed: 3000-4000rpm
Spindle diameter: 30mm
Scoring saw: 0-45 °
Main motor: 4KW
Model axis: 40 * 1300mm
Net weight: 500kg
Electrical configuration: Chint
